Portable Gis Collector/GPS Receiver with High Accuracy

Portable Gis Collector/GPS Receiver with High Accuracy
Price: US $ 0.1/Set
Trade Terms: FOB,CFR,CIF
Min Order: 1/Set
Pay Type: L/C,T/T,Western Union
Prod Model: Qstar8 Portable GIS Collector
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
CPU: 806MHz Hi-Speed CPU
Internal Memory: 256MB
Flash Memory: 8GB
Resolution: 640*480
Dustproof And Waterproof: IP67
Battery Power: 8800mAh
Weight: 835g
Pixel: 500 Million
Support: GPS.Gloss,Compass...
Static Measurement: 5mm+/-1ppm
Type: GPS Receiver
Use: Automotive&Hand Held
Screen Size: 3.7 Inch
Brand: Hi-Target
Certification: CE

Product Description

*Main advantages of the portable GPS handheld GIS collector
>Faster
 Microsoft Windows Mobile 6.5
 806MHZ high-speed CPU
 256M RAM, 8G flash memory
>Higher accuracy
 GPS+GLONASS+COMPASS
 Advanced PPP technology
>Solider
 1.5M anti-drop, IP67
 Integrated elaborate double color model


*Main features of the handheld GPS receiver:
5 million pixel auto focus camera
Accurate centering mode
Integrated high accuracy G-sensor, Centering GNSS antenna phase center accurately
Electronically level GNSS antenna


Multiple wireless communication modes
Integrated 3G communication function, Supports all 3G communication systems
Integrated Bluetooth, WIFI, USB communication , Makes wirelessly assist telemeter &detecting instrument etc. to work synchronously.

GNSS positioning technology
With reliable GPS+GNSS positioning technology, you can work normally even under hard environmental conditions.
Support COMPASS satellite navigation system.
Advanced PPP technology realizehigher accuracy even just adopt single point positioning.

3.7 inch QVGA TFT, resolution: 640×480

8800mAh Li-ion battery, over 12 hours' continuous work


*Technical parameter of the portable GPS handheld GIS Collector/GPS receiver:

Model
Qstar 8
System ConfigurationOperation system: Windows Mobile 6.5
Processor: 806 MHZ
RAM: 256MB RAM
Flash Memory: 8GB
Display: 3.7 inch LED, 640×480 resolution
GNSS featuresDual frequency GPS+GLONASS
Support Compass system
Integrate SBAS (WAAS, EGNOS, MSAS)
Time for the first fix(TTFF): 30 seconds
Update rate: 1HZ (support higher frequency)
Position AccuracySingle point positioning2m
SBAS1< 50 cm
Reference station differential2cm
Static surveying5mm±1ppm
Application functionsIntegrated 3G communication module
5 million pixel camera with LED
Built-in microphone & speaker
Integrated G-sensor
Integrated laser plummetoptional
9 keys, with the four arrow keys and camera key
Data communicationBluetooth
Mini USB
WIFI:802.11b/g
MicroSD card slot, support up to 32GB
Power supply8800mAh lithium battery, online charging
Over 12 hours continuous work
Physical propertiesSize:236mm×105mm×62mm
Weight: 835g(with battery)
Operating temperature: -30ºC ~ +70ºC
Storage temperature: -40ºC ~ +80ºC
Dustproof/waterproof: IP67
Anti-shock: 1.5m free fall
