| Prod Model: |
Qstar8 handheld GPS receiver |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Operation System: |
Windows CE |
| Memory: |
256m |
| Flash Memory: |
8g |
| Screen: |
2.8",Color Touch Screen |
| Main Function: |
Compass,Barometric Altimeter,Thermometer |
| Waterproof/Dustproof: |
IP67 |
| Anti-Drop: |
1.5m |
| Software: |
Vehicle Navigation |
| Static Measurement: |
5mm+/-1ppm |
| Use: |
Hand Held |
| Type: |
GPS Navigation and Tracking |
| Model: |
Qcool |
| Screen Size: |
2.8" |
| Brand: |
Hi-Target |
| Certification: |
CE,FC |
Product Description
***Main Features of the portable GPS handheld GPS receiver***
*Faster
Microsoft Windows Mobile 6.5
806MHZ high-speed CPU
256M RAM, 8G flash memory
*Higher accuracy
GPS+GLONASS+COMPASS
Advanced PPP technology
*Solider
1.5M anti-drop, IP67
Integrated elaborate double color model
***Main features of the GPS receiver***
5 million pixel auto focus camera
Accurate centering mode
Integrated high accuracy G-sensor, Centering GNSS antenna phase center accurately
Electronically level GNSS antenna
Multiple wireless communication modes
Integrated 3G communication function, Supports all 3G communication systems
Integrated Bluetooth, WIFI, USB communication , Makes wirelessly assist telemeter &detecting instrument etc. to work synchronously.
GNSS positioning technology
With reliable GPS+GNSS positioning technology, you can work normally even under hard environmental conditions.
Support COMPASS satellite navigation system.
Advanced PPP technology realizehigher accuracy even just adopt single point positioning.
3.7 inch QVGA TFT, resolution: 640×480
8800mAh Li-ion battery, over 12 hours' continuous work
***Technical parameter of the portable GPS handheld GPS receiver***
Model | Qstar 8 |
| System Configuration | Operation system: Windows Mobile 6.5 | √ |
| Processor: 806 MHZ | √ |
| RAM: 256MB RAM | √ |
| Flash Memory: 8GB | √ |
| Display: 3.7 inch LED, 640×480 resolution | √ |
| GNSS features | Dual frequency GPS+GLONASS | √ |
| Support Compass system | √ |
| Integrate SBAS (WAAS, EGNOS, MSAS) | √ |
| Time for the first fix(TTFF): 30 seconds | √ |
| Update rate: 1HZ (support higher frequency) | √ |
| Position Accuracy | Single point positioning | 2m |
| SBAS1 | < 50 cm |
| Reference station differential | 2cm |
| Static surveying | 5mm±1ppm |
| Application functions | Integrated 3G communication module | √ |
| 5 million pixel camera with LED | √ |
| Built-in microphone & speaker | √ |
| Integrated G-sensor | √ |
| Integrated laser plummet | optional |
| 9 keys, with the four arrow keys and camera key | √ |
| Data communication | Bluetooth | √ |
| Mini USB | √ |
| WIFI:802.11b/g | √ |
| MicroSD card slot, support up to 32GB | √ |
| Power supply | 8800mAh lithium battery, online charging | √ |
| Over 12 hours continuous work | √ |
| Physical properties | Size:236mm×105mm×62mm | √ |
| Weight: 835g(with battery) | √ |
| Operating temperature: -30ºC ~ +70ºC | √ |
| Storage temperature: -40ºC ~ +80ºC | √ |
| Dustproof/waterproof: IP67 | √ |
| Anti-shock: 1.5m free fall | √ |
Qstar 8
The most portable handheld RTK
Centimeter level high accuracy
Dual frequency GPS+ GNSS positioning
Meet your surveying requirements even under hard environmental conditions and most extreme weather conditions
