Industrial Tension and Compression Load Cell

Name: Industrial Tension and Compression Load Cell
Brand: all-electronics-online.com
SKU: 827806665
Availability: InStock
Rating: 5 (35 reviews)

Price:	US $ 30-34/Piece
Min Order:	2/Piece
Pay Type:	L/C,T/T,Western Union,Paypal,Money Gram

Contact Supplier

Showroom Product Company Profile

Prod Model:	B353
Out-Wire:	5 Wires
Feature:	High Accuracy
Production Process:	Strain Gauge
Material:	Alloy Steel

Product Description

Name: Tension and Compression crane Load Cells
Capacity: 1t
Material/production class: Alloy steel or Stainless steel

1	Specifications	Technique
2	Capacity	500kg, 1-5T, 7.5-10T, 15-20T
3	Rated output	2.0±0.005mV/V 3.0±0.005mV/V
4	Zero balance	±1.0% F.S.
5	Non-linearity	0.02%F.S.
6	Hysteresis	±0.02% F.S.
7	Repeatability	0.01%F.S.
8(30min)	Creep(30min)	0.02%F.S./10ºC
9	Temp.effect on output	0.02%F.S./10ºC
10	Temp.effect on zero	0.02%F.S./10ºC
11	Input impedance	385±10Ω
12	Output impedance	350±3Ω
13	Insulation	≥5000MΩ/100VDC
14	Recommended excitation	10V
15	Maximum excitation	15V
16	Compensated temp range	-10~50ºC
17	Operation temp range	-20~60ºC
18	Safe overload	120%F.S.
19	Ultimate overload	200%F.S.
20	Cable size	Φ5.4×5000mm
21	Material	Alloy or Stainless Steel
22	IP Class	IP67 / IP68

Fully sealed up to IP67/68
High Accuracy
High Endurance
Built in Overload Protection
High Capacity / Low Capacity
Compact designs available for tight environment
In both Tension and Compression
Single Point Construction
5. Instruction:
Brans S-Beam Load Cells combine compact structure with enhanced precision and rigorous testing to form a reliable and durable tension and compression force transducer. The one-piece design achieves an accuracy of ±0.02 % full scale.

What you could get from Brans?

Load Cells, Miniature and sub-miniature force sensors, Pressure Transducers/sensors, Torque Transducers, Temperature sesensors, Flow senesors, Displacement Transducers (LVDTs), Digital Gauges, Strain Gauges, Instrumentation for Test, amplifiers and data acquisition systems as well as software for structural durability investigations, tests and analysis, Measurement and Other Applications.

Why choose Brans?

Brans cooperate with HBM, FLINTEC, METTLER TOLEDO, Honeywell, Vishay and other famous brand electronic measuring instruments and system. We could learn and get the most advanced technology and news of procedures. Good manufactures means good products.

We could OEM for miniature and sub-miniature load cells with tension or compression; Big capacity load cells/sensors Brans also could make it with good quality material.

Brans products (load cells, force sensors, amplifiers… ) have been certified per ISO9001, OIML, CE, RoHS, NETP AND ATEX. Brans could promise you the best quality for measuring products.

Who Brans cooperate with?

Brans have developed solutions for a wide range of industries including automotive, aerospace, military and defense, oil and gas, R&D and material/test labs, machine and automation equipment designers and builders, off highway and heavy equipment manufacturers, medical device manufacturers, semiconduct or fabricators, utilities and energy companies, marine equipments and shipbuilding.
