Big Capacity Ss S Load Cell

Name: Big Capacity Ss S Load Cell
Brand: all-electronics-online.com
SKU: 687712891
Availability: InStock
Rating: 4.5 (143 reviews)

Price:	US $ 45-50/Piece
Min Order:	2/Piece
Pay Type:	L/C,T/T,Western Union,Paypal,Money Gram

Contact Supplier

Showroom Product Company Profile

Prod Model:	B315
Capacity:	250n-100kn
Out-Wire:	5 Wires
Feature:	High Accuracy
Production Process:	Strain Gauge
Material:	Alloy Steel

Product Description

1. Name:HBM RSCC stainless steel S-Type Tension Load Cell(also S-Beam Load Cell)
2. Type: B315

3. Specifications:
Brans miniature S-Beam Load Cells combine compact structure with enhanced precision and rigorous testing to form a reliable and durable tension and compression force transducer. The one-piece design achieves an accuracy of ±0.05 % full scale. The lower capacity (2.5 N to 500 N) Miniature capacity are constructed from aluminum; whereas higher capacity load cells are made with stainless steel. B315 could get high accuracy with compact size. So we could use this for small limitied space force measurement.

	Specifications	Technique
	Capacity	50,100,200,500,1000,2000, 3000,5000kg
	Rated output	2.0±0.25%mV/V
	Zero balance	0.01mV/V
	Non-linearity	0.018%F.S.
	Hysteresis	±0.018% F.S.
	Repeatability	0.018%F.S.
	Creep(30min)	0.024%F.S.
	Temp.effect on output	0.014%F.S./10ºC
	Temp.effect on zero	0.017%F.S./10ºC
	Input impedance	350±5Ω
	Output impedance	350±5Ω
	Insulation	≥5000MΩ/100VDC
	Recommended excitation	5V
	Maximum excitation	15V
	Compensated temp range	-10~40ºC
	Operation temp range	-30~70ºC
	Safe overload	150%F.S.
	Ultimate overload	300%F.S.
	Cable size	Φ5.4×3000mm
	Material	Stainless Steel
	IP Class	IP68

Features
Tension and compression load/force measurement
Wide capacity range: 2.5N to 500N
Accuracy: ±0.05 %FS
Metric thread
One-piece,17-4 stainless steel or aluminum construction
Overload capacity: 150 %FS
IP67 sealing

www.bransensor.com

What you could get from Brans?

Load Cells, Miniature and sub-miniature force sensors, Pressure Transducers/sensors, Torque Transducers, Temperature sesensors, Flow senesors, Displacement Transducers (LVDTs), Digital Gauges, Strain Gauges, Instrumentation for Test, amplifiers and data acquisition systems as well as software for structural durability investigations, tests and analysis, Measurement and Other Applications.

Why choose Brans?

Brans cooperate with HBM, FLINTEC, METTLER TOLEDO, Honeywell, Vishay and other famous brand electronic measuring instruments and system. We could learn and get the most advanced technology and news of procedures. Good manufactures means good products.

We could OEM for miniature and sub-miniature load cells with tension or compression; Big capacity load cells/sensors Brans also could make it with good quality material.

Brans products (load cells, force sensors, amplifiers… ) have been certified per ISO9001, OIML, CE, RoHS, NETP AND ATEX. Brans could promise you the best quality for measuring products.

Who Brans cooperate with?

Brans have developed solutions for a wide range of industries including automotive, aerospace, military and defense, oil and gas, R&D and material/test labs, machine and automation equipment designers and builders, off highway and heavy equipment manufacturers, medical device manufacturers, semiconduct or fabricators, utilities and energy companies, marine equipments and shipbuilding.
