Prod Model: |
HP-CP100 |
Section Thickness Range: |
1-35μm |
Minimum Setting Value: |
1μm |
Precision Error: |
±1% |
Maximum Specimen Size: |
60 X 40mm |
Pre-Setting Temperature Range: |
Ambient to -55ºC |
Maximum Temperature Range For Cryo-Plate: |
≥60ºC |
Maximum Temperature Range For Cryo-Prob: |
≥50ºC |
Maximum Size Of Cryo-Pate: |
45 X 40mm |
Dual Function Section: |
Freezing and Paraffin Use. |
Working Voltage: |
AC200V 50Hz or AC110V 60Hz |
Product Description
1.1 Description
It adopt high-power semi-conductor freezing system and advanced nano material. LCD shows setting and current temperature, self-temperature control, self-protection systems an defrost function etc.
This model adopts streamline design, advanced function, stable performance, user-friendly. Specimen feed drive is controlled by intelligent control system. Precise electrical mechanical design, Ergonomic concept.
1.2 Specification
Main Technical Parameters:
Section thickness range:1~35μm
Minimum setting value: 1μm
Precision error: ±1%
Maximum specimen size: 60 x 40mm
Dural purpose of blade holder, high profile blade or low profile blade can be changed
Steel knife holder or disposable blade holder can be changed
Pre-setting temperature range: ambient~-55ºC
Maximum temperature range for Cryo-plate ≥60ºC
Maximum temperature range for Cryo-probe: ≥50ºC
Maximum size of Cryo-pate: 45 x 40mm
Pre-setting and current temperature shown in LCD
Best section angle between Cryo-probe and section blade is 60 degrees
Temperature of defrost display ,pre-setting temperature can be stored itself after working
Temperature of section can be reached after freezing within 1~7 minutes
Dual function section: freezing and paraffin use.
Working voltage:AC200V 50Hz,AC110V 60Hz
Power draw:300VA
Computer Fast and Constant-cooling Freezing and Paraffin Microtome |
Section thickness range | 1~35μm |
Minimum setting value | 1μm |
Precision error | ±1% |
Maximum specimen size | 60 x 40mm |
Pre-setting temperature range | ambient~-55ºC |
Maximum temperature range for Cryo-plate | ≥60ºC |
Maximum temperature range for Cryo-probe | ≥50ºC |
Maximum size of Cryo-pate | 45 x 40mm |
Dual function section | freezing and paraffin use. |
![](/proimages/44f3j00jEhQAocqnnkt/semi-conductor-computer-fast-and-constant-cooling-freezing-and-paraffin-microtome.jpg)
![](/proimages/44f3j00bQiEyUkFZNqP/semi-conductor-computer-fast-and-constant-cooling-freezing-and-paraffin-microtome.jpg)
![](/proimages/44f3j00cTVENuksZnbD/semi-conductor-computer-fast-and-constant-cooling-freezing-and-paraffin-microtome.jpg)
![](/proimages/44f3j00ctWQyLkUgNoP/semi-conductor-computer-fast-and-constant-cooling-freezing-and-paraffin-microtome.jpg)
![](/proimages/44f3j00othQyicEgNbP/semi-conductor-computer-fast-and-constant-cooling-freezing-and-paraffin-microtome.jpg)
![](/proimages/44f3j00bTWQFqcEHnkD/semi-conductor-computer-fast-and-constant-cooling-freezing-and-paraffin-microtome.jpg)
