Trinocular Stereo Inspection Microscope for Semiconductors (XTS-3022)

Trinocular Stereo Inspection Microscope for Semiconductors (XTS-3022)
Price: Negotiable/Piece
Trade Terms: FOB,CIF,EXW
Min Order: 1/Piece
Pay Type: T/T,Western Union
Prod Model: XTS-3022
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Eyepiece: Wf10X/22
Zoom Ratio: 1:8.3
Lens Zoom Range: 0.6X-5X
Total Magnification: 6X-50X
Field Of View: 36.7mm-4.4mm
Working Distance: 95mm
Interpupillary Distance: 48mm-75mm
Binocular Or Trinocular Tube: Inclined 45
Diopter Adjustment: 5 Diopter
Binocular Body Rotation: 360
Type: Stereomicroscope
Mobility: Desktop
Shape: Single-lens
Principle: Optics
Magnification: 10-83X
Number Of Cylinder: Trinocular

Product Description

Usage:
This stereo microscope is widely used in medical and health, electronics, precision machinery industry and so on, specially suitable to inspect the naked IC, LCD printing paste, PCB board, LED production, stamping parts, plated parts and electronic components

Feature:
1) Zoom lens microscope 2) Big working table
3) Parallel Beam Path Design 4) Can connect CCD camera

Standard delivery:
Main unit: 1PCS Eyepiece patch: 2PCS
Anti-dust cover: 1PCS

Optional accessories for this microscope:
Eyepiece: WF5X, WF15X, WF20X, WF25X, WF30X
Objective: 0.5x, 0.75x, 1.5x, 2x
Micro-image process software Digital Camera

Technical data:
zoom ratio1: 8.3
Objective lens zoom range0.6X-5X
EyepieceWF10X/22mm
Total magnification6x-50x
Field of view¢ 36.7mm-¢ 4.4mm
Working distance95mm
Interpupillary distanceAdjustable 48mm-75mm
Trinocular tubeInclined 45º
Diopter adjustment± 5 diopters
Trinocular body Rotation360º
Power supply110V/60HZ or 220V/50HZ
Top halogen lamp6V, 15W adjustable brightness
Bottom fluorescent lamp5W

EyepieceWF10X WFl5XWF20XWF25X
Auxiliary lensMagnificationField of viewMagnificationVisual fieldMagnificationField of viewMagnificationField of viewWorking distance(mm
0.5X3X-25X¢ 73-¢ 8.84.5X-37.5X¢ 53.3-¢ 6.46X-50X¢ 43.3-¢ 5.27.5X-62.5X¢ 40-¢ 4.8200
0.75X4.5X-37.5X¢ 49-¢ 5.96.75X-56.25X¢ 35.5-¢ 4.29X-75X¢ 28.8-¢ 3.511.25X-93.8X¢ 26.6-¢ 3.2125
1X6X-50X¢ 36.7-¢ 4.49X-75X¢ 26.7-¢ 3.212X-100X¢ 21.6-¢ 2.615X-125X¢ 20-¢ 2.495
1.5X9X-75X¢ 24.4-¢ 2.913.5X-112.5X¢ 17.7-¢ 2.118X-150X¢ 14.4-¢ 1.722.5X-187.5X¢ 13.3-¢ 1.655
2X12X-100X¢ 18.4-¢ 2.218X-150X¢ 13.3-¢ 1.624X-200X¢ 10.8-¢ 1.330X-250X¢ 10-¢ 1.235
Dongguan Leader Precision Instrument Co., Ltd. is a hi-tech enterprise specializing in R&D, production and sales of optics, machinery and electronic precision measuring and testing instruments, our range includes: Video measuring system, profile projector, coordinate measuring machine, measuring microscope, linear scale and digital readout, video measuring machine, optical comparator, VMM, VMS, vision measuring machine, non-contact 2D video measuring system, Hardness tester, and also stereo microscope, biological microscope, LCD inspection microscope, metallographic microscope etc which are widely used in metrological, measuring, inspecting, testing and reverse engineering fields.

Our continuous excellent products supply sustainable value for our large client word-wide. With powerful strength and good reputation, our products have been exported to more than 30 countries. We are committed to raise the standards of our products and improve the services. We are dedicated to ensure superior products, timely delivery, competitive price and excellent after-sale service

We have a proficient and strong workforce, comprising of technically skilled professionals, who have rich experience in dimension measurement and data analysis in machinery, mould, electronic, aviation, automobile, plastic, gear, PCB circuit board, spring, connector, semiconductor, precision parts and so on.

We guarantee quality and high performance of our products and offer excellent services. Our continuous effort towards producing superior quality products and perfection has helped us to win the trust, confidence and assurance of the customers from all over the globe. Our products have received a great response and recognition in the customers. You can depend on our products for superiority, reliability and durability.
