Prod Model: |
ES-20161213 |
OEM: |
Yes |
Armoured: |
Available |
Insulated Color: |
Red,Green,Blue,Yellow |
Test Report: |
Yes |
Manufacturer: |
Since 2006 |
Factory Area: |
200, 081mm2 |
Sample: |
Free |
Capacity: |
100, 000m/Day |
Delivery Length: |
Accord with The Request |
Shipping Term: |
by Express or Sea |
Application: |
Telecommunication |
Voltage: |
Low and Medium Voltage Cable |
Current: |
DC & AC |
Insulation Material: |
XLPE |
Certification: |
TUV |
Wire Core Material: |
Flexible Copper Wire |
Model: |
Es-201609-05 |
Brand: |
Asian Sun |
Product Description
Solid Conductor Type and Copper Conductor Material copper power cables
Company Information
Luoyang Asian Sun Industrial Group Co., Ltd. was established in 2006 with RMB 50 million registerde capital in Luoyang, Henan Province, China. Now our total assets is RMB 300 million. The company covers an area 61,081 square meters, and has 4 affiliates with more than 300 employees including 15 engineers and technicians.Features/Description
XLPE insulated power cable not only has excellent electric, mechanic properties, but also has powerful resistance chemical corrosion, anti-aging and long life.
Voltage grade is up to 26/35kv, cross-section area is up to 630 sq-mm ( copper or aluminum conductor). The core number of conductor is from 1 to 5. Conductor long-time operating temperature is 90 degrees. In short circuit, conductor highest temperature should be not more than 250 degrees.Application
It is generally applied to the fields including substation, construction, mines, metallurgy, petrochemical industry for transmission and distribution electric energy. For laying indoor, tunnel, cable trench and underground.
Structure:
Single core: 1.5 mm2 ~ 400 mm2
Two-cores: 2x1.5mm2 ~ 2x400mm2
Three-cores: 3x1.5mm2 ~ 3x400mm2
Four-cores: 4x1.5mm2 ~ 4x400mm2
(3+1) cores: 3x2.5+1x1.5mm2 ~ 3x400+1x185mm2
Five cores: 5x1.5mm2 ~ 5x400mm2
(4+1) cores: 4x2.5+1x1.5mm2 ~ 4x400+1x185mm2
(3+2) cores: 3x2.5+2x1.5mm2 ~ 3x400+2x185mm2
Properties of XLPE Power Cable
1.The highest allowed operating temperature of conductor for long-term working is 90 degrees.
2.In short circuit (Max long term is no more than 5 seconds). The highest temperature for conductor is no more than 250 degrees.
3.The cable is laid without horizontal drop limit. The environment temperature should be no lower than 0 when lay. Otherwise it should be preheated.
4.Excellent electrical performance, resistance to chemical corrosion.
5.Can stand advisable traction when laid.Can stand traction from Outside.Left low smoke halogen-free after burned.Retard the burning of the cable.
Type | Name of product | Applicability and surroundings |
Cu | Al |
YJV | YJLV | XLPE insulated PVC sheath power cable | For laying indoors , in tunnel or cable trench,unable to bear external mechanical forces,Single-core cable in magnetic duct is not permissible |
YJY | YJLY | XLPE insulated PE sheath power cable |
YJV22 YJY22 | YJLV22 YJLY22 | XLPE insulated steel tape armored PVC sheath power cable | For laying indoors , in tunnel, cable trench, or direct in ground,able to bear external mechanical forces, but unable to bear large pulling force |
YJV23 YJY23 | YJLV23 YJLY23 | XLPE insulated steel tape armored PE sheath power cable |
YJV32 YJY32 | YJLV32 YJLY32 | XLPE insulated thin steel-wire armored PVC sheath power cable | For laying indoors , in tunnel, cable french, well or direct in ground,able to bear external mechanical forces, and certain force . |
YJV33 YJY33 | YJLV33 YJLY33 | XLPE insulated thin steel-wire armored PE sheath power cable |
YJV42 YJY42 | YJLV42 YJLY42 | XLPE insulated thin steel -wire armored PVC sheath power cables |
YJV43 YJY43 | YJLV43 YJLY43 | XLPE insulated thin steel -wire armored PE sheath power cables |
Packaging & Shipping
It will be package according to its outside diameter and weight by drum or wooden reel.
1.We use the fumigated &treated timber wooden box to package cables,
2. Wooden package optional:
Size: 0.5*0.5*0.5m or as you required.
0.6*0.6*0.6m
0.7*0.7*0.7m
1.1*1.1*0.8m
1.8*1.8*1.1m
2.2*2.2*1.8m
3. Wooden plate sealed.
4. Suitable meters according to your size.
5. 72 pcs of 0.7m wooden reel can be put in one 20FCL.
28 pcs of 1.1m wooden reel can be put in one 20FCL.
6 pcs of 1.8m wooden reel can be put in one 20FCL.
Our Service
Luoyang Asian Sun Industrial Group Co., Ltd, a professional wires and cables manufacturer for 6 years in China. Asian Sun attends International Exhibitions every year, we mainly produce power cables, control cables, aerial overhead cables(ABC, AAC ACSR and AAAC cables) and solar pv cables etc. Standards Supported: ASTM, BS, CSA, IEC, DIN and GB etc.
1. Factory: 200,081 square meters, available for OEM;
2. Lead time: 5-7 working days after payment received;
3. Authentication: TUV, OHSAS, CCC, CQC, ISO9001:2008;
4. Payment terms: T/T, L/C, O/A;
5. Guarantee: 20 years;
6. QC inspection: Strict inspection before delivery;
After-sales Service
1. All our cables will be tested well in production and before delivery.
2. Please contact us if any problem, we will respond within 24 hours.
