Small gear electrical DC 24V brushless motor for astronomical instruments

Prod Model:	DC Planetary Gear Motors TRS-775PM-2460
Product Name:	DC Planetary Gear Motors TRS-775PM-2460
No-load Speed:	6.3-1400 rpm
Rated Speed:	5.7-1125rpm
Rated Torque:	2.8-100kg.cm
Rated Current:	2.3-8.7mA
Output Power:	32-40W
Max.momentary Tolerance Torque:	11-300kg.cm
Rated Voltage:	6V 12V 24V
No-load Current:	0.3-1.2mA
Stall Torque:	3600g.cm
Application:	Power Tools
Operating Speed:	Low Speed
Structure And Working Principle:	Brushless
Excitation Mode:	Permanent Magnet
Type:	DC Planetary Gear Motors
Certification:	RoHS CE
Brand:	TT motor

Product Description

Small gear electrical dc 24v brushless motor for astronomical instruments

Main Features
1.OEM/ODM 42mm planetary gearbox plups7 series dc motor and 42mm brushless motor
2.Small size dc gear motor with low speed and big torque
3.42mm gear motor provide 10.0Nm torque and more reliable
4.Suitable to small diameter, low noise and big torque application
5.Dc Gear motors can match encoder,11ppr
6.Reduction ratio:4,14,19,27,51,71,100,139,189,264,369,516,720


Motor model no.	Rated voltage	No-load speed	No-load current	Rated speed	Rated torque	Rated current	Output power	Stall torque	Stall current
	VDC	r/min	A	r/min	g.cm	A	W	g.cm	A
TRS-775PM-2460	24	6000	0.3	4500	900	2.3	40	3600	7.2
TRS-775PM-0648	6	4800	1.2	3600	900	8.7	33	3600	32
TRS-775PM-1246	12	4600	0.6	3470	900	4.4	32	3600	16

Gear motor technical data : GMP42-775PM-2460-xxx

Reduction ratio	4	19	51	100	139	189	264	369	516	720
Length  mm	31.5	42	52	52	52	62	62	62	62	62
No-load speed  rpm	1400	295	110	58	42	32	23	16	11.5	8.3
Rated speed  rpm	1125	235	88	45	32	24	18	14	10.5	8
Rated torque  kg.cm	2.8	13	26	51	71	89	100	100	100	100
Max.momentary tolerance torque  kg.cm	11	54	110	216	300	300	300	300	300	300

Gear motor technical data : GMP42-775PM-0648-xxx

Reduction ratio	4	19	51	100	139	189	264	369	516	720
Length  mm	31.5	42	52	52	52	62	62	62	62	62
No-load speed  rpm	1150	240	92	46	35	25	18	13	9.3	6.6
Rated speed  rpm	900	190	71	36	26	19	14	11	8.5	6.0
Rated torque  kg.cm	2.8	13	26	51	71	89	100	100	100	100
Max.momentary tolerance torque  kg.cm	11	54	110	216	300	300	300	300	300	300

Gear motor technical data : GMP42-775PM-1246-xxx

Reduction ratio	4	19	51	100	139	189	264	369	516	720
Length  mm	31.5	42	52	52	52	62	62	62	62	62
No-load speed  rpm	1100	220	86	44	32	24	17	12	8.7	6.3
Rated speed  rpm	870	185	69	35	25	19	14	10.5	8.2	5.7
Rated torque  kg.cm	2.8	13	26	51	71	89	100	100	100	100
Max.momentary tolerance torque  kg.cm	11	54	110	216	300	300	300	300	300	300

Product Application

Other Applications:
Business Machines:	ATM, Copiers and Scanners, Currency Handling, Point of Sale, Printers, Vending Machines.
Food and Beverage:	Beverage Dispensing, Hand Blenders, Blenders, Mixers, Coffee Machines, Food Processors, Juicers, Fryers, Ice Makers, Soy Bean Milk Makers.
Home Entertainment and Gaming:	Gaming Machines, Video Games, Optical Disk Drives, RC and Power Toys.
Home Technologies:	Home Ventilation, Air Purifiers and Dehumidifiers, Range Hoods, Washers and Dryers, Refrigerators, Dishwashers, Floor Care, Whirlpool and Spa, Showers, Smart Metering, Coffee Machines.
Lawn and Garden:	Lawn Mowers, Snow Blowers, Trimmers, Leaf Blowers.
Personal Care:	Hair Cutting, Hair Care, Massagers.
Power Tools:	Drills and Drivers, Sanders, Grinders, Polishers, Saws.
Camera and Optical:	Video, Cameras, Projectors.
