Packaging Diodes1n4148ws/Bav16ws

Name: Packaging Diodes1n4148ws/Bav16ws
Brand: all-electronics-online.com
SKU: 729932982
Availability: InStock
Rating: 5 (47 reviews)

Price:	Negotiable/Piece
Min Order:	3000000/Piece
Pay Type:	T/T

Contact Supplier

Showroom Product Company Profile

Prod Model:	1N4148WS/BAV16WS

Product Description

1N4148WS is a small signal switching diode, the package is in addition to patch SOD-323, glass red tube plug DO-35, SMD LL-34, SOD-123 SOD-523 SOT-23 different plastic patch package, power 200mW, current 0.15A, voltage VR:75V, switching time of Trr:4nS, since it is a switching diode, switch is used, through his switch time, you know that it is in the circuit on the "open" and "off", composed of guide for biantong cut-off or cut off by conduction into the time required shorter than the general diode.

1N4148WS is small signal switching diode, encapsulation is patch SOD - 323, and another glass sealed red tube plug-ins DO - 35, patch LL - 34, encapsulation SMT SOD - 123 SOT SOD - 523-23 different packaging, such as shape, power 200 mw, 0.15 A current, voltage VR: 75 v, switch time Trr: 4 ns, since be switching diode, is done using the switch, switching time through his term, will know that it is in the circuit to "open" or "off", it by conduction into globe or by the deadline to the time needed for conducting shorter than general diode.
Features
1,It's one kind of high frequency switching diode.Including DO35, LL34, SOD323, SOT23, encapsulation were 0805.
2,75 v reverse pressure and average forward current 150 ma, very suitable for do general rectifier with general occasions.
3,4 pf junction capacitance and 4 ns of reverse recovery time enough for most situations.
4,Very easy to get, and the price is low, generality of a small signal high frequency diode.

Established in 2000, Changzhou Zhongguang Electronic Co., Ltd(ZG), which locates in Changzhou city, Jiangsu province, a place concentrated with China's most vigorous manufacturers, our company has a wide variety of products with complete specifications, including diodes, bridge rectifiers and automotive rectifier diodes, transient voltage suppressors(TVS), general rectifier(STD), fast recovery diode(FR), high efficiency rectifiers(HER/UF), super fast recovery diodes(SF) and schottky diodes(SKY). The main package includes A-405, DO-41, DO-15, R-1, R-6, DO-201AD. TO-220AB. TO-220AC, SMA, SMB, SMC, MBS, MBM, DBS, dB, WOB, RS-2, GBJ2, KBPC1, KBP, KBL, GBJ4, KBU, GBJ6, GBU, KBPC6, KBPC8 etc.

And the company untroduced a full set of advanced equipment and scientific management system from abroad. The quality of our products enjoys a good reputation in domestic and foreign markets. The company could supply competitive price and fast delivery and good quality with prompet service.

Our products are widely used in the fields like home appliances, LED, energy saving lamp, smart electric meters, security and protection, extinguishing and protection and automotive electronics etc.
