Microscope for Semiconductors Inspecting and Measurement (LD-250)
| Price: |
US $ 1000-2000/Piece |
| Trade Terms: |
FOB,CIF,EXW |
| Min Order: |
1/Piece |
| Pay Type: |
T/T,Western Union |
| Prod Model: |
LD-250 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Name: |
Microscope |
| Model: |
Ld-250 |
| Total Magnification: |
18.2-117X |
| Valid Pixel: |
5.0 Mega Pixels |
| Screen Size: |
9 Inch LCD Screen |
| Display Resolution: |
1280*800 |
| Video Output: |
Synchronized Display |
| Memory Card: |
Support SD |
| Objective: |
0.7X-4.5X |
| Illumination: |
LED Cold Ring Light |
| Type: |
Video |
| Number Of Cylinder: |
Monocular |
| Mobility: |
Desktop |
| Shape: |
Rectangular Prism |
| Principle: |
Optics |
| Magnification: |
18.2X-117X |
Product Description
Feature:The patented LD-250 industrial microscope offers a range of excellent optics depending on your budget. Compared with traditional microscope over periods of time, operatos will notice allot less muscle fatigue, so performance improves as well.
This unique outfit also allows you to display and capture real-time, high-resolution video images.
Capturing and storing images and video clips on the optional SD card can be easily transferred to your personal computer.
The digtla LCD microscpe widely used to measure, test and inspect in product assembly, research and teaching fields.
| Total magnification | 18.2-117X |
| Valid pixel | 5.0 Mega pixels |
| Display screen | Size | 9 Inch LCD screen |
| Display resolution | 1280*800 |
| Video output | Synchronized display |
| Memory card | SupportSD |
| Objective | Zoom lens 0.7x-4.5x |
| Illumination | LED cold ring light |
| Measurement | Cross hair |
| Digital video and sound interface | HDMI |
| Working stage | X-axis travel | 30mm |
| Y-axis travel | 30mm |
| Measuring accuracy | 5 micron |
| Load | 6kg |
| Power supply | 12V |
| Language | English, German, French, Japanese, Russian, Spanish, Korean, Arabic, Latin |
Dongguan Leader Precision Instrument Co., Ltd. is a hi-tech enterprise specializing in R&D, production and sales of optics, machinery and electronic precision measuring and testing instruments, our range includes: Video measuring system, profile projector, coordinate measuring machine, measuring microscope, linear scale and digital readout, video measuring machine, optical comparator, VMM, VMS, vision measuring machine, non-contact 2D video measuring system, Hardness tester, and also stereo microscope, biological microscope, LCD inspection microscope, metallographic microscope etc which are widely used in metrological, measuring, inspecting, testing and reverse engineering fields.
Our continuous excellent products supply sustainable value for our large client word-wide. With powerful strength and good reputation, our products have been exported to more than 30 countries. We are committed to raise the standards of our products and improve the services. We are dedicated to ensure superior products, timely delivery, competitive price and excellent after-sale service
We have a proficient and strong workforce, comprising of technically skilled professionals, who have rich experience in dimension measurement and data analysis in machinery, mould, electronic, aviation, automobile, plastic, gear, PCB circuit board, spring, connector, semiconductor, precision parts and so on.
We guarantee quality and high performance of our products and offer excellent services. Our continuous effort towards producing superior quality products and perfection has helped us to win the trust, confidence and assurance of the customers from all over the globe. Our products have received a great response and recognition in the customers. You can depend on our products for superiority, reliability and durability.
