Mechanical Hygrostat Mfr 012, Thermostat

Name: Mechanical Hygrostat Mfr 012, Thermostat
Brand: all-electronics-online.com
SKU: 792948385
Availability: InStock
Rating: 4.9 (148 reviews)

Price:	Negotiable/Piece
Min Order:	10/Piece
Pay Type:	L/C,T/T,Western Union,Paypal,Money Gram

Contact Supplier

Showroom Product Company Profile

Prod Model:	MFR 012
Range 1:	0-60
Range 2:	-40-60
Dimension:	675038

Product Description

Product Description:
Mechanical Hygrostat MFR 012
Adjustable relative humidity
Change-over contact
High switching capacity
Easily accessible terminals
Clip fixing
The electromechanical hygrostat MRF 012 is designed to control enclosure heaters so that the dew point is raised when a critical relative humidity of 65% is exceeded. In this way condensation and corrosion is effectively preven
Technique parameter:

Technical

Switch difference*	4% RH (±3% tolerance)
Permissible air velocity	15m/sec
Contact type	change-over contact
Service life	> 50,000 cycles
Min. switching capacity	20V AC/DC 100 mA
Max. switching capacity	25VAC, 5A
	DC 20W
Connection	3-pole terminal for 2.5mm⊃2;, clamping torque 0.5Nm max.: rigid wire 2.5mm⊃2;, stranded wire (with wire end ferrule) 1.5mm⊃2;
Mounting	clip for 35mm DIN rail, EN60715
Casing	plastic according to UL94 V-0, light grey
Dimensions	67 x 50 x 38mm
Weight	approx. 60g
Fitting position	variable
Operarting/Storage temperature	0 to +60°C (+32 to +140°F) / -40 to +60°C (-40 to +140°F)
Operating / Storage humidity	max. 90 % RH (non-condensing)
Protection type	IP20
Approvals
*at 50% RH

Technical

Art. No.	Setting range
01220.0-00	35 to 95% RH

*at 20°C (68°F) ambient temperature
