LC Fiber Optic Loopback Device
| Price: |
US $ 20-40/Meter |
| Min Order: |
1/Meter |
| Pay Type: |
L/C,T/T,D/P,Western Union,Paypal |
| Prod Model: |
053265 |
| Connector A: |
MPO Female (pinless) |
| Connector B: |
LC UPC Duplex |
| Fiber Mode: |
OS2 9/125um |
| MPO Connector RL: |
20dB |
| LC Connector RL: |
20dB |
| Jacket OD: |
3.0mm |
| Fan-Out Diameter: |
2.0mm |
| Cable Jacket: |
PVC |
| Fiber Count: |
12 |
Product Description
LC Fiber Optic Loopback Device
PUNO provides cables with standard MTP connectors.The MTP connector uses the MT ferrule, which allows users to bundle multiple channels into one single connector. The most common configurations are single and double row with 12 and 24 channels respectively, but they can be configured to 72 channels housed in just one MTP? connector. The channels are precisely aligned using two guide pins on the male connector, and the push-pull housing allows for easy removal without the risk of accidental disconnections. The connector is compatible with bare ribbon fiber, round loose tube jacketing, stainless steel jacketing, and many other jacketing options. PUNO also manufactures breakout cables, network simulation modules (TM Boxes), and loopbacks with the MTP connector. Benefits: High quality components and design with low insertion loss; Push-pull design for easy and secure (stable) connections; High capacity with up to 72 fiber counts; 100% optically tested ensures reliability and performance.
Application
MPO/MTP is the high dense degree of optical fiber pre-connect system,which is generally use in three areas.
- The data centra application with high dense degree environment;
- The optical fiber to the building;
- The internal connector application in fiber equipment such as Splitter, 40G/100G SFP and SFP.
MPO/MTP trunk cables
- MPO/MTP trunk cables are used to interconnect cassettes, panels or ruggedized MPO fan-outs, spanning MDA, HAD and EDA zones, and easy to rapid deployment of high density backbone cabling in data centers and other high fiber environments reducing network installation or reconfiguration.
- MPO/MPT trunk cables using a compact and rugged microcable structure, according to different colors divided into SM, MM and 10G MM. The fiber ranges from 12 to 144, MTP polarity options are TIA way is Style A(up), Style B(down) and Style C(up/up). The cable length belongs to a custom product, please kindly email your requirements to us!
Features
- With 12-fiber and 24-fiber MPO/MTP connector standard
- Available in OS1/2, OM2, OM3 and OM4
- Available in FC,LC, SC, ST, MU, and MTP
- Interface polished type has PC, UPC and APC
- Available in 12/24/36/48/72/96/144-fibers
- 100% factory tested
- Discrete connectors are heat-cured and use ceramic ferrules and sleeves
- Fan-out fibers from MPO/MTP connectors into individual simplex or duplex
- Customized for length, staggering, connector type, breakout style, fiber count, and labeling fiber
Pre-terminated MPO/MTP Technology-Polarity
The three polarity methods Type A, Type B and Type C are used to guarantee the right bi-directional allocation. | 40G: 1 x 12F MPO / MTP® Fiber Chart |
| Fiber Color | MPO / MTP® | | MPO / MTP® |
| Blue | Rx | | Tx |
| Orange | Rx | | Tx |
| Green | Rx | | Tx |
| Brown | Rx | | Tx |
| Not Used | N/A | ................... | N/A |
| Not Used | N/A | ................... | N/A |
| Not Used | N/A | ................... | N/A |
| Not Used | N/A | | N/A |
| Slate | Tx | | Rx |
| White | Tx | | Rx |
| Red | Tx | | Rx |
| Black | Tx | | Rx |
| Fiber Type (ISO/IEC 11801) | 50/125um, OM4, Violet |
Attenuation Coefficient
[dB/km] | ≤3.5 Max (850nm)
≤1.5 Max (1300nm)
≤2.7 Typ. (850nm)
≤0.9 Typ. (1300nm) |
| Minimum Bandwidth: Overfilled Launch [Mhz-km] | ≥1500 (850nm)
≥500 (1300nm) |
| Minimum Bandwidth: Laser Effective Modal Bandwidth[Mhz-km] | ≥2000 (850nm) |
Jacket Material | Riser - OFNR
LSZH - Low Smoke Zero Halogen
Plenum - OFNP |
Ordering Guide
(1)The big length with pulling eyes for each reel packed.
(2) The fiber channeling of our 40G/100G Solution will be illustrated in NEATEL drawings, please contact us more details.
(3) The MPO / MTP® Trunk Assemblies in our 40G/100G Solution are connected via key-up to key-up MPO adapter (Type-B),please contact us if different adapter orientation is required.
(4) Please refer to the "MPO Trunk Assembly" leaftlet if MPO assemblies with 12-Fiber cable or other fiber counts are needed.
