| Prod Model: |
CY-JMD-09V03 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Rated Current: |
60A |
| Coil Voltage: |
12V/18V/24V/48V/96V |
| Rated Voltage: |
6V/9V/12V/24V/48V |
| Number Of Coil: |
Single or Double |
| Terminal: |
Assembly with CT or /Shunt |
Product Description
Character
Rohs compliance
large switching power with mini body
big strength of magnetic latching power
anti shock and vibration
short time pulse drive
economic power consumption and no heat rising
keep stability with permanent magnetic strength
power saving
small contact resistance
little self-consumption
reliable working
- Character
Meet to IEC62055-31-2005-UC2According to RoHS requirementsLarge switching power with mini bodyBig strengthof magnetic latching power,anti-shock of vibration Pulse drive,economy of power consumption and no heat rising Permanent magnetic strength to keep stability,and save power consumption Small contact resistance ,and little self-consumption with reliable working - Application
Electronic energy meter Automatic meter reading system Lamp controller Complex switch Home appliance and automatic control equipment - Coil Specification
| Rated voltage | Action voltage (VDC) | Max coil voltage(V) | Coil resistance x(1±10%)Ω | Rated power |
| Single coil | Double coil |
| 6 | 4.8 | 12 | 36 | 18+18 | Single coil 1W
Double coil 2W |
| 9 | 7.2 | 18 | 81 | 40.5+40.5 |
| 12 | 9.6 | 24 | 144 | 72+72 |
| 24 | 19.2 | 48 | 576 | 288+288 |
| 48 | 38.4 | 96 | 2304 | 1152+1152 |
- Technical Specification
| Contact type | 1B(1A) | Insulation resistance | ≥1000MΩ(500VDC) |
| Contact material | AgSoO2 | Dielectric strength | Coil--contact | ≥4000VAC 1min |
| Contact--contact | ≥1500VAC 1min |
| Contact load (resistance) | 60A 250VAC | Action time | close | ≤20mS |
| open | ≤20mS |
| Contact resistance (mΩ) | ≤2mΩ | Action impulse duration | 50mS-240mS |
| Max switching voltage | 250VAC | Life (time) | Electrical life(ops) | 1x 104 (circle) |
| Mechanical life (ops) | 1x 106 (circle) |
| Max switching current | 60A | Max action frequency | 1200 ops/h |
| Max switching power | 15KVA | Vibration tolerance | 98m/s2 |
| Short time impact current | 2500A 10ms no sinter
4500A 10ms no explosion | Shock tolerance | 10-50Hz 1.0mm |
| Ambient temperature | -40ºC to +70ºC
| Relative humidity | 90% RH 40ºC |
- Dimension
- Wiring Diagram
Remarks: - The drawing does not show tolerance. It is subject to below range:
≤1mm ±0.21-5mm ±0.3≥5mm ±0.4 - The output terminal in above drawing is for customers'reference only. The dimension and connection way of output terminal can be customerized.
