Fp10000q High Output Switch PRO Amplifier for Line Array & Subwoofer
Price: |
US $ 620-630/Piece |
Min Order: |
2/Piece |
Pay Type: |
T/T,Western Union,Money Gram |
Prod Model: |
FP10000Q |
Type: |
Professional Amplifier |
Usage: |
Outdoor |
Used For: |
Professional |
Tube Type: |
Transistor Amplifier |
Function: |
Pre-amplifier |
Sound Channel: |
4.1 |
Output Number: |
4 |
Element Number: |
Monoamplifier |
Conductive Mode: |
D |
Voltage: |
110V or 220V |
Product Description
FP10000Q high quality audio sound professional power amplifier with CE ROHS 1year warranty
Product Description:
FP series is a high performance switching power amplifier, compact structure, reasonable; each channel with independent adjustable peak output voltage, the amplifier can be very easy to drive different power sizes speakers ; intelligent protection circuit provides advanced technology to protect the internal circuits and connected loads, can in extreme conditions to protect the amplifier and speakers. For large-scale performances, venues, business senior entertainment clubs and other places.
compact zize, light weight, big power output, and high stability.
be suitable for pro audio proformance for indoor or outdoor . FP Series | FP7000 | FP9000 | FP14000 | FP6000Q | FP10000Q |
Output Power | 20-20kHz, 1W with 1 khz |
8ΩStereo Power(RMS) | 1500WX2 | 1800WX2 | 2400WX2 | 700WX4 | 1300WX4 |
4ΩStereo Power(RMS) | 2800WX2 | 3000WX2 | 4400WX2 | 1300WX4 | 2100WX4 |
2ΩStereo Power(RMS) | 3500WX2 | 4500WX2 | 7000WX2 | 1500WX4 | 2500WX4 |
8ΩBridged Power(RMS) | 5600W | 6000W | 8800W | 2500WX2 | 4200WX2 |
4ΩBridged Power(RMS) | 7000W | 9000W | 14000W | 3000WX2 | 5000WX2 |
Frequency Response(+o/-0.3dB,1W/8Ω) | 20 Hz - 34 kHz |
THD 20 Hz - 20 kHz for 1 W | <0.1% |
Signal-to-Noise Ratio | >112 dBA |
Channel separation (Crosstalk) at 1 kHz | >70 dB |
Input Connectors (per channel) | 3-pin XLR, electronically balanced |
Output Connectors (per channel) | Binding Posts 2-pole |
Class | TD |
TourClass Protection | ACL,IGM, AutoRamp, short circuit, DC voltage, turn-on/off transient, current inrush, sub/ultrasonic input |
Operating voltage, 230 V / 115 V nominal | 130-265 V / 65-135 V selectable |
Voltage Gain(dB) | 23, 26, 29, 32, 35, 38, 41, 44 dB selectable |
Input impedance | 20 kOhm |
Level adjustment (per ch.) | Front-panel potentiometer, 31 position detented from -inf to 0 dB |
Dimensions (W×H×D) | 483×88×396mm |
Packing dimension | 560×180×500mm |
Net weight(kg) | 15 |
Gross weight(kg) | 19 |
1. Q: What is the whole process for doing business with us ? |
A: 1) First,please tell me which model ,Voltage,Plug style of amplifier you need. 2) We will make provide Proforma Invoice for client to arrange payment. 3) We will arrange to produce at once when we get 30% deposit or full payment. 4) We will send photos of all goods,packing,details for client after goods are finished.We will arrange shipment and provide original B/L after the client pay 70% balance before shipment. If shipped by Air,we will tell you tracking number within 1-2days. |
|
2. Q: Can the logo or company name to be printed on the products or package? |
A: Yes, we are manufacturer, we accept OEM request! |
|
3.Q:Is it with LAB gruppen logo ? |
A:Yes, we can supply logo for you. |
|
4. Q:Can it work under 2 ohms stably? |
A:Yes, it can. However to protect your speakers and amplifier lifespan,we suggest you don't use it under 2ohms for a long time. |
|
5. Q:Can I pay by Paypal,Escrow or Credit card ?What is the payment terms? |
A:Yes,you can !For sample or small order(under 3000USD), we accept the payment sent by Western Union, Paypal,escrow; For bulk orders, we can accept Western Union or T/T .Please contact our sales person. He/She will be your guide. |
|
6. Q:How good is your after service? |
A:We support 1 years warranty.If any problems during this period, we will sent you free replacements to repair, anyway we will find the best solution for you! |
![](/proimages/44f3j00VuzTjhlyvtqQ/fp10000q-high-output-switch-pro-amplifier-for-line-array-subwoofer.jpg)
![](/proimages/44f3j00ipzEKklBqtba/fp10000q-high-output-switch-pro-amplifier-for-line-array-subwoofer.jpg)
![](/proimages/44f3j00izptjvhaTToE/fp10000q-high-output-switch-pro-amplifier-for-line-array-subwoofer.jpg)
![](/proimages/44f3j00lzgQsKhSOtka/fp10000q-high-output-switch-pro-amplifier-for-line-array-subwoofer.jpg)
![](/proimages/44f3j00VpzTKFisJacQ/fp10000q-high-output-switch-pro-amplifier-for-line-array-subwoofer.jpg)
Payment methods1.T/T;2.Western Union;3.Money Gram;4.Cash.Transportation methods1. By air to airport;2. By sea to seaport;3. By EXPRESS door to door, DHL, TNT, FEDEX, UPS, EMS etc. Our service:Pre-sale ServiceA. Quality is our company's culture.B. Reasonable price and reliable service.C. Rich experience of design, manufacture and sell Pro-audio, Speakers, amplifiers.Middle-sale ServiceA. Checking the most suitable shipping ways for customers.B. Testing quality again before sending goods.C. Sending the tracking number/bill of loading, and update the situations of the goods till customers receive the goodsAfter-sale serviceA. We are very glad that customer give us some suggestion for price and products.B. If you have any question, please contact with us freely by E-mail or Telephone.Our advantages:- Experienced staff answer all your questions with fluent English.
- Specialized in speakers over 16 years in China.
- Quality is the soul of our enterprise.
- We think our products will give you an edge over your competitors.
- Hope fully to become yours trustworthy company in China.
- Welcome OEM and ODM.
Our company supplies different kinds of products. High quality and favorable price. We're pleased to get your Inquiry and we will come back to as soon as possible. We stick to the principle of "quality first, service first, continuous improvement and innovation to meet the customers" for the management and "zero defect, zero complaints" as the quality objective. To perfect our service, we provide the products with good quality at the reasonable price.
Founded in 2002, we specialized in the manufacturer of high performance professional loudspeakers. In addition to designing and distributing components under the Ganyon brand name, we also supply OEM components to most of the top professional audio brands in the market today.
With more than 65 employees (5% of which are engaged in our Research and Development department), Ganyon Speakers designs, produces and trades all of its products directly from its head office, located in Guangzhou city, Panyu district.
Ganyon Speakers primary line consists of high frequency drivers, coaxial components and cone drivers. We have made a strong commitment to provide a well-balanced line of Low Frequency drivers that range from 6" to 21", as well as a very complete line of High Frequency drivers. We have made refinements in areas such as high frequency diaphragm technology, cone geometry, magnet assemblies, chassis design and much more, to create a dynamic and powerful line-up of components.
Our engineers have optimized each design with fine software to ensure each design operates to its fullest potential time and time again. From nightclubs, to stadiums, to concert halls around the world, our speakers are chosen based on their reliability, consistency and most of all for their outstanding sound quality.
Our Quality Control Department inspects 100% of products.
As for the productions, an automatic check is conducted on Frequency response, Impedance curve, rub & buzz, polarity and T-S parameter of each speaker.
