| Prod Model: |
YZX-FPC |
| Color: |
According to Your Design |
| Feature: |
Enclosed and Waterproof |
| Insulation Ink Voltage: |
100VDC |
| Custom Made: |
OEM/Customize |
| Conductive Ink: |
Screen Printing Silver Ink, Carbon Ink |
| Pattern Of Payment: |
L/C, T/T, Dp, Western Union, Paypal, Money Gram |
| Package: |
Inner; Vacuum Packing; Dry Packing out Packing |
| Back Adhesive: |
3m9449 3m467 3m468 3m200 |
| Transportation: |
by Ship/by Air/by Land |
| Type: |
Flexible Circuit Board |
| Dielectric: |
FR-4 |
| Material: |
Fiberglass Epoxy |
| Flame Retardant Properties: |
V0 |
| Application: |
Industry Control |
| Brand: |
Yizexin |
Product Description
Product Description
Shenzhen Yizexin High quality flexible printing circuit
Main Material and Technical Specifications:| Name: | FPC Process Capability |
Number of Layers | Single Sided, Double Sided, Multilayer,Rigid-flex PCB |
Based Material | PI, PET |
Certificate: |
OHSAS18001:2007,ISO14001:2004,ISO/TS16949:2009,
ISO13485:2003,TUV,UL,SGS,ROHS,FCC,CCC,CE,ASTM-F963-16 |
| Custom Made: | OEM/customize |
| Flexible layers | 1~8layer |
| Minimum Trace and Space | 12&18um(base Cu):0.075/0.075mm ;35um(base Cu):0.1/0.1mm |
| Minimum Space Betw en Coverlay Openings | 0.2mm |
| Minimum Space between coverlay and solder pad | 0.15mm |
| Polyimide Films | 0.5 mil (12.5), 1 mil (25), 2 mils (50), 3 mils (75), 4mils(100), 5 mils(125) as custmer requested |
| Thermobond Adhesives | Acrylic/Modified Acrylic, Modified Epoxy, Polyimide |
| Copper Foils (RA or ED) | 1/3oz (12), 1/2oz (18), 1oz (35), 2oz (70) |
| Surface Finish | Electroless Ni/Au, Electrolytic soft/hard gold, Tin plating,,Imm.Tin,Entek/OSP |
| Solder Resists | Coverlay, Photo-Imagable Resist |
| Copper Plated Thickness(PTH only) | 8~15um;20~30um;30~70um(special) |
| Minimum space between coverlay and conductor | ± 0.15mm |
| Minimum conductor edge to outline edge | ≥0.1mm |
Au thickness
| Electroless Ni/Au Ni:2~6um;Au:0.035~0.075um Electrolyticsoft/hardgoldNi:2~9um;Au:0.035~0.1um |
| Smallest Drill Size | 0.2mm |
| Largest Drill Size | 6.3 |
A blend of rigid and flex emphasizing the best of both constructions, adding complimenting capabilities that neither possess alone. In its most typical configuration, the rigid-flex is as a series of rigid PCBs joined by integrated flex circuits (with emphasis on the high percentage of rigid area content). There are many excellent possibilities for circuits designed primarily as a flex circuit with the addition of integrated rigid areas. The rigid areas provide excellent hard mount points for components, connectors and chassis while flex areas offer dynamic flexing, flex to fit, and component mounting poised to take advantage of these low mass and vibration resistant zones. This blending leads to creative solutions for your most demanding applications.
Multilayer flex circuits offer exceptional performance and reliability in situations where the circuit is exposed to excessive vibration or shock combined with frequent bending or folding. Multilayer technology allows high circuit density connections to be achieved in applications where one or two layers of conductors could not meet the required circuit packaging requirements. Additionally, multilayer flex circuits provide increased functionality with a smaller footprint.bout our company:
We have three companies,more than 500 workers in it.Our companies are specialized in the production of membrane switch,nameplate,lenses,crystal glue Acrylic craftwork,cartoon frameand so on.We have large dust-free workshop,full automatic silk screen printing machine,colorprinting machine,CNC engraving and milling machine,numerical control cutting machine,punchandsomeothermodernproductiondevices.BT,,SEMTECH,Emerson,Delong,FerroliMotorola,Haier,Electrolux,Guangbao are all our cooperate partners. We are authorized by such as China famous quality products,quality service productsAAAenterprise,OHSAS18001:2007,ISO14001:2004,ISO/TS16949:2009ISO13485:2003,TUV,UL,SGS,ROHS,FCC,CCC,CE,ASTM-F963-16.I can assure you of our best qualitly. Look forward to cooperating with you .
Our factories have three companies: Shenzhen Yizexin Technology Co., Ltd., Yizexin(HK)Technology Co., Ltd, Shenzhen ankang sports equipment Co., Ltd, Our company supplies different kinds of products. Each products is: Membrane Switch and Membrane Panel, Flexible Circuit, Lenses Series, Stickers Series, crystal Glue, Roll up Piano, Roll up Drum, Hand Spinners, Hand Cube, Acrylic ornament, Acrylic key chain, etc., our factory more than 500 people, We have our own Exhibition Workshop, Dust-Free Workshop, Laboratory, 6 Color Printing Machine, Automatic Screen Printing Machine, Cutting Machine, etc., We has also our own development teams and foreign trade teams. We also passed the ISO9001, SGS certification, Our products also the CE, FCC, RoHS, CPC certification, etc. Also has our own product patent, the Disney authorization for 3 years, Foxconn Appointed Supplier. All products are exported to Japan, Europe, America, Italy, Germany, Korea, Mexico, India and other foreign markets. High quality and favorable price. We stick to the principle of "quality first, service first, continuous improvement and innovation to meet the customers" for the management and "zero defect, zero complaints" as the quality objective. To perfect our service, we provide the products with good quality at the reasonable price. Welcome to your visit and order!
