Product Description
factory selling 3000w pure sine wave solar power inverter with digital meter
Product Feature
1. Factory unhybrid solar inverter
2. LED indicator
3. 12 months warranty
4. OEM service
5. Package: Blister inner packing,carton mass packing.
6.Offer battery cable
7.High conversion efficiency,quickly start;
8.Stable function, High Flexibility in any kinds of load power
9.Excellent double-faced circuit board and components
10.Heat-Sink built in internal and come with Auto temperature control fan for heat dissipation
11.CE EMC LVD ISO certification
Protection Funtion
1. LED Indicator 2. Buzzer Alarm 3. Over-Load Protection 4. Over-Voltage Protection 5. Low-Voltage Protection 6. Over-Temperature Protection 7. Short-circuit protection
Why Choose Pure Sine Wave Inverter ?
The pure sine inverter,also referred to as a "true" sine wave, is known as a pure sine wave
inverter can play all kinds of electronic equipments such as Laptop,Television,refrigerator, Lights, sensitive medical equipment and many more without any lines through screen or making
noise when the equipment runs.
Application
1) In-car or on-boat devices series: Military vehicle, police cars, medical ambulance, ships, traffic lights, and etc.
2) Industry equipments series: Solar energy, wind power, gas discharge lamp and etc.
3) Office area: Computer, printer, copier, scanner,and etc.
4) Kitchen utensils series: Micro-wave oven, induction cooker, refrigerator, and etc.
5) House appliance devices: Electric fans, vacuum cleaner, lighting lamps and etc.
6) Power tool series: drilling machine, punching machines, air compressors.
Guangzhou Suredom electronic &technology Co.,Ltd brief introduction
Established in early 1998, Guangzhou Suredom electronic &technology Co.,Ltd has become not only a manufacturer, but also a trading company. Now we have about 400 staff. We have our own Production Line, Testing Department, Maintenance Department, Warehouse, Sales Department and Research&Development Department.
Our Factory is a manufacturer with more than 10-year inverter producing experience, specializing in off-grid single-phase pure sine wave/modified sine wave power inverters, solar charge controllers, battery chargers, step-down converters, power adapters and cellphone chargers etc. We have introduced international advanced technology with fully automated production lines, advanced machines and instruments for multi-function testing and aging testing.
We are an ISO 9001:2008 certified factory with all our products being CE, EMC, LVD, EU certified.
We can provide OEM service. Currently, our products are exported to America, Europe,the Middle East and many other areas. Our products are so warmly welcome among customers.
Add: 4F&5F, Self-Compiled Plant B1, Industrial Zone, No. 63, Longdong Yinglong Street, Tianhe Dist., Guangzhou, Guangdong, China (Mainland)
FAQ &Warranty
Q1. The electric appliance doesn't work and the indicator light isn't on.
Reason:
1. Faulty battery.
2. Wrong connection of positive pole and negative pole.
3. Loose connection of the cables.
Answer:
1. Check the battery, and change it if needed.
2. Check the connection of battery. The inverter might be damaged and should
be changed or sent to be repaired.
3. Check the cables and connection points, and tighten the terminals.
Q2. The electric appliance doesn't work and the RED indicator light is on.
Reason:
1. The rated power of electric appliance exceeds the nominal power of inverter
which leads to over load shut down.
2. The rated power of electric appliance is less than the nominal power of the inverter
but its peak power is too high which leads to over load shutdown
3. The electricity in battery runs out (the inverter alarms)
4. Poor ventilation causes over heat shutdown
5. Input voltage is too high.
Answer:
1. Please use the electric appliance which power is less than the nominal power of inverter.
2. The peak power of electric appliance is no more than that of power inverter, or the same power.
3. Charge the battery or change it.
4. Turn off the inverter for 15 minutes, remove the items near fan and those around the inverter,
and put the inverter in a shady and cool place
5. Turn off the inverter and test the output voltage of battery.
Q3. The output voltage of power inverter tested is too low.
Reason: Generally the numerical reading range of voltmeter for testing use is too small.
Answer: If you test the output voltage of modified sine wave inverters, please use "true RMS
Muti-meter" to obtain the accurate data.
Q4. Only small power load can be driven.
Reason: When the current goes through the cables, the voltage declines.
Answer: Shorten the length and use thicker cables.
Q5. The hours of use are too short.
Reason:
1. The electricity consumption of the electric appliance is larger than rated load of power inverter.
2. The battery is faulty or damaged
3. The battery is not well charged
4. The current declines when through cables
Answers:
1. Use larger capacity battery.
2. Change battery.
3. If the charger can't charge the battery fully, it needs to change a better intelligent charger.
4. Shorten the length of the cables and use the thicker cables.
Q6. How to contact your esteemed company and buy the inverters?
Reason:
We are in the different regions, but we want to establish the long business with your and your excellent
commodity.Contacts Welcome to contact Selina
