Factory Price 25mm High Torque 24V Electric DC Motor
Price: |
US $ 7-14/Piece |
Min Order: |
1/Piece |
Pay Type: |
L/C,T/T,Western Union |
Prod Model: |
PG25370 gear motor |
Product Name: |
Pg25370 Series, 25mm Diameter Planet Gear Motor |
Motor Type: |
Carbon-Brush Commutator |
Gear Type: |
Straight Gearwheel, Planet Construction |
Housing Material: |
Steel |
Geartrain Material: |
Steel and Powdered Metal, POM Optional |
Bearing At Output Shaft: |
Sleeve Bearing |
Lubricant: |
Grease for High-Low Temperature, -62---+204 Degree |
Backlash At No-Load: |
<1°, Min0.3° |
OEM & ODM Service: |
Available |
Life Time: |
1000h+ |
Application: |
Power Tools |
Operating Speed: |
Constant Speed |
Structure And Working Principle: |
Brush |
Certification: |
ISO/Ts16949/Ce/Rhos |
Brand: |
Twirl |
Product Description
factory price 25mm high torque 24v electric dc motorProduct Category
China manufacturer gear motor price With Professional Technical Support
We always provide customers with distinctive products:cost-effective, lower
noise, higher efficiency and stability, longer life and higher strength. Basic information |
Product name | PG25370series,25mm diameter planet gear motor |
Motor type | carbon-brush commutator |
Gear type | Straight gearwheel,planet construction |
Housing material | Steel |
Geartrain material | Steel and Powdered Metal,POM optional |
Bearing at output shaft | Sleeve bearing |
Lubricant | Grease for high-low temperature, -62---+204 degree |
Backlash at no-load | <1°,MIN0.3° |
OEM & ODM Service | Available |
Certificate | CE,ROHS,ISO/TS16949 |
An exact model of gearbox and motor combination |
Product seires | PG25370 series |
An exact Model NO. | PG25370 24 6000-198K |
Motor Voltage(VDC) | 24 |
Motor no load speed(rpm) | 6000 |
Gearbox reduction ratio | 198K |
Gearmotor no load current(A) | <0.039 |
Gearmotor no load speed(rpm) | 29+/-10% |
Gearmotor rated load torque(kgf.cm) | 6.3 |
Gearmotor rated current(A) | <0.194 |
Gearmotor rated load speed(rpm) | 24+/-10% |
Noise (DB) | <55DB |
Lifetime | 1000+ hours (varies by application) |
Rotation | CW/CCW reversible |
Packing&Shiping
Company Information
FAQ
Q: Are you a trading company or a manufacturer?
A: We are a manufacturer.
Q: Can you make a motor with custom specifications?
A: Yes, actually that is what we do most of the time.
Q: What is the MOQ (minimum order quantity)?
A: 1 pc for sample order, and 100pcs for bulk order.
Q: Do you have motors in stock?
A: No, we don't. All motors are made with orders.
Q: How to pay you?
Paypal, Western Union, Money Gram, T/T, L/C payment are acceptable.
Q: What do you need to know if I need a recommendation on motor?
A: Normally we need to know dimensions, rated voltage, speed at load/no load, torque at load/stall. i.e.
a motor with diameter 37mm, 12V, 100rpm and 2Kgf.cm at load.
Q: Can I ask you for help if I know nothing about motor?
A: Yes, our pleasure. We are nice people with big hearts.
Q: Can we type our brand on it?
A: Yes of course.
Q: Where is your loading port ?
A: Ningbo Port, Shanghai Port, China.
Q: What is your production capacity?
A: About 4000 PCS per day.
Q: Can I visit your factory?A: Yes,of course
