Euro Schuko Plug 3 Round Pin to IEC320 C13 AC Power Cord 1.8m

Name: Euro Schuko Plug 3 Round Pin to IEC320 C13 AC Power Cord 1.8m
Brand: all-electronics-online.com
SKU: 837452425
Availability: InStock
Rating: 4.6 (95 reviews)

Price:	Negotiable/Piece
Min Order:	500/Piece
Pay Type:	L/C,T/T,Western Union

Contact Supplier

Showroom Product Company Profile

Prod Model:	Power Cord (H05VV-F 3G*0.75)
Plug:	Cee7/7 Schuko Plug
Female End Type:	IEC320 C13
Rated Current:	10A/16A
Voltage:	250V
Model:	Schuko Power Cord to C13
Insulation Material:	PVC
Approval:	IEC320
Cable:	H05VV-F 3*0.75mm2-1.5mm2
Conductor:	Bare Copper
Grounding:	Standard Grounding

Product Description

Schuko power cord to iec 60320 c13, schuko cable to c13, ,
Schuko cable to c13 ,VDE power plug,

3A 5A 10A 13A 250V
H03VV-F 3x0.5-0.75MM2
H05VV-F 3x0.75-1.5MM2
H03RT-F 3x0.75-1.5MM2
H05RN-F 3x1.0-1.5MM2

Product Name	European type power cable to IEC connector C13
Plug	CEE7/7 Schuko Plug
IEC Connector	IEC320 C13 right angle/ 90 degree type
Conductor	100% Copper
Cable	H05VV-F 3*0.75mm2-1.5mm2
Length	6 feet ,1.8m ,can be customized
Jacket	PVC/Rubber
Rating	16A,250V
Certification	CE,VDE
Application	Home Appliance ,Laptop,TV,Power adapter...

specification		Conductor	Normal thickness of insulation mm	Normal thickness of jacket mm	Over diameter mm	Max conductor resistance at 20°C ≤Ω/km	Ampere rating A
No. of core	normal cross-sectional area of conductor mm 2	No. / Dia. mm	Normal thickness of insulation mm	Normal thickness of jacket mm	Over diameter mm	Max conductor resistance at 20°C ≤Ω/km	Ampere rating A
1	1.5	30/0.25	0.8	1.4	5.8~6.7	13.3	27
	2.5	49/0.25	0.9	1.4	6.5~7.2	7.98	37
	4	56/0.30	1.0	1.5	7.6~8.5	4.95	47
	6	84/0.30	1.0	1.6	8.5~9.5	3.30	52
2	1	32/0.20	0.8	1.3	8.2~9.1	19.5	17
	1.5	30/0.25	0.8	1.5	9.1~10.1	13.3	21
	2.5	49/0.25	0.9	1.7	10.9~12.4	7.98	30
	2×4	56/0.30	1.0	1.8	12.9~14.8	4.95	39
	3×6	84/0.30	1.0	2.0	14.7~16.6	3.30	51
3	3×1	32/0.20	0.8	1.4	8.9~9.9	19.5	12
	3×1.5	30/0.25	0.8	1.6	9.8~11.1	13.3	18
	3×2.5	49/0.25	0.9	1.8	11.7~13.4	7.98	26
	3×4	56/0.30	1.0	1.9	13.8~15.7	4.95	34
	3×6	84/0.30	1.0	2.1	15.7~17.6	3.30	43
