Prod Model: |
SQC |
Rated Power: |
5W |
Rated Load: |
1-6t |
Display Mode: |
4-Digit Nixie Tube Display |
Sensor Overload Capacity: |
150% |
Working Voltage: |
AC180-260V |
Sensor Working Voltage: |
DC5-12V |
Working Temperature: |
-20-60 Degree |
Sensitivityof The Sensor: |
1.0000mv/V |
Operating Humidity: |
95% |
Sensorprotection Level: |
IP65 |
Product Description
Electrical Load Limiter sensor for construction hoist suspended platform is mounted between the bottom surface of the lift cage construction with additional steel plate down by the weight of the pressure sensor to measure the weight of a weak strain and weight signals into electrical signals to pass through the transmission cable weight limit device .
Construction hoist overload protection is coming from the sensor signal by the limiter summing amplifier , A / D converter , microcontroller operation , when the weight lifting cage reaches or exceeds the set value , the corresponding relay respectively within the limiter actions connected with the elevator control system to insure lift safe and reliable.
Specifications - Electrical Load Limiter sensor for construction hoist suspended platform
mobile crane load moment indicator | C2 |
Max. Capacity(Emax) | 0.75,1,1.5,2,3,4,5t |
Minimum LC verification interval | Emax/5000 g |
Maximum number of load cell verification intervals | 2000 |
Rated output | 1.0±0.01/0.7±0.01(5t) |
Temperature effect on zero balance | ±0.02%FS/10°C |
Temperature effect on sensitivity | 20~40°C | ±0.02%FS/10°C |
-10~20°C | ±0.02%FS/10°C |
Combined error | ±0.500%FS |
Creep(in 30 min) | ±0.300%FS |
Zero balance | 1%FS |
Input resistance(RLC) | 750±10Ω |
Output resistance(RO) | 703±2Ω |
Insulation resistance(Ris) at 100 VDC | ≥5000 MΩ |
Service temperature range | -10~+70°C |
Storage temperature range | -20~+70°C |
Reference excitation voltage | 10~15 V |
Safe load limit(EL) | 150%FS |
Breaking load(Ed) | 200%FS |
Material | Alloy steel |
Protection class | IP67 |
Cable | Length:4m Diameter:φ5mm |
