Prod Model: |
XTS-2023 |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Wf10X/23mm: |
10-83X |
Stereoscopic Effects: |
Yes |
Structure: |
Refractor Telescope |
Lens Type: |
Zoom Lens |
Lens: |
Glass |
Objective Aperture: |
>50mm |
Focusing Type: |
Center Focusing |
Aperture: |
<50mm |
Model: |
Xts |
Name: |
Stereo Microscope |
Type: |
Biological |
Number Of Cylinder: |
Binoculars |
Mobility: |
Desktop |
Shape: |
Rectangular Prism |
Principle: |
Optics |
Magnification: |
10-83X |
Product Description
Binocular Inspection Stereo Microscope for Semiconductors (XTS-2023)Usage:This stereo microscope is widely used in medical and health, electronics, precision machinery industry and so on, specially suitable to I nspect the naked IC, LCD printing paste, PCB board, LED production, stamping parts, plated parts and electronic components
Feature:1) Zoom lens microscope
2) Big working table
3) Parallel Beam Path Design
4) Can connect CCD camera
Standard delivery:Main unit: 1PCS
Eyepiece patch: 2PCS
Anti-dust cover: 1PCS
Optional accessories for this microscope:Eyepiece: WF5X, WF15X, WF20X, WF25X, WF30X
Auxiliary lens: 0.5x, 0.75x, 1.5x, 2x
Technical data: |
zoom ratio/range | 1: 8.3 |
Objective lens zoom range | 0.6X-5X |
Eyepiece | WF10X/22mm |
Total magnification | 6-50X |
Field of view | 36.7mm-4.4mm |
Working distance | 95mm |
Interpupillary distance | Adjustable 48mm-75mm |
Binocular tube | Inclined 45º |
Diopter adjustment | ± 5 diopters |
Binocular body Rotation | 360º |
Eyepiece | WF10X | WF15X | WF20X | WF25X | |
Auxiliary lens | Magnification | Field of view | Magnification | Visual field | Magnification | Visual field | Magnification n | Visual field | Working distance(mm |
0.5X | 3X-25X | 73-8.8 | 4.5X-37.5X | 53.3-6.4 | 6X-50X | 43.3-5.2 | 7.5X-62.5X | 40-4.8 | 200 |
0.75X | 4.5X-37.5X | 49-5.9 | 6.75X-56.25X | 35.5-4.2 | 9X-75X | 28.8-3.5 | 11.25X-93.8X | 26.6-3.2 | 125 |
1X | 6X-50X | 36.7-4.4 | 9X-75X | 26.7-3.2 | 12X-100X | 21.6-2.6 | 15X-125X | 20-2.4 | 95 |
1.5X | 9X-75X | 24.4-2.9 | 13.5X-112.5X | 17.7-2.1 | 18X-150X | 14.4-1.7 | 22.5X-187.5X | 13.3-1.6 | 55 |
2X | 12X-100X | 18.4-2.2 | 18X-150X | 13.3-1.6 | 24X-200X | 10.8-1.3 | 30X-250X | 10-1.2 | 35 |
