Binocular Inspection Stereo Microscope for Semiconductors (XTL-2024)

Binocular Inspection Stereo Microscope for Semiconductors (XTL-2024)
Price: Negotiable/Piece
Trade Terms: FOB,CIF,EXW
Min Order: 1/Piece
Pay Type: T/T,Western Union
Prod Model: XTL-2024
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Eyepiece: Wf10X/22
Zoom Ratio: 1:8.3
Lens Zoom Range: 0.6X-5X
Total Magnification: 6X-50X
Field Of View: 36.7mm-4.4mm
Working Distance: 95mm
Interpupillary Distance: 48mm-75mm
Binocular Or Trinocular Tube: Inclined 45
Diopter Adjustment: 5 Diopter
Binocular Body Rotation: 360
Type: Stereomicroscope
Number Of Cylinder: Binoculars
Mobility: Desktop
Shape: Rectangular Prism
Principle: Optics
Magnification: 10-70X

Product Description

Usage:
This stereo microscope is widely used in medical and health, electronics, precision machinery industry and so on, specially suitable to inspect the naked IC, LCD printing paste, PC

Feature:
1) Zoom lens microscope
2) Erect image
3) Can connect CCD camera

Standard delivery:
Main unit: 1PCS
Eyepiece patch: 2PCS
Anti-dust cover: 1PCS

Optional accessories this microscope:
Eyepiece: WF5X, WF15X, WF20X, WF25X, WF30X
Auxiliary lens: 0.5x, 0.75x, 1.5x, 2x
Technical data
Zoom ratio1: 7
Lens zoom range0.65X-4.5X
EyepieceWF10X/20mm
Total magnification65X-450X
Field of view¢ 30.7mm-¢ 4.4mm
Working distance95mm
Interpupillary distance55mm-75mm
Binocular tubeinclined 45º
Diopter adjustment± 5 diopter
Binocular body rotation360º
Power supply110V/60HZ or 220V/50HZ
Top halogen lamp6V, 15W adjustable brightness
Bottom fluorescent lamp5W

EyepieceWF10XWF15XWF20XWF25X
Auxiliary lensMagnificationField of viewMagnificationField of viewMagnificationField of viewMagnificationField of viewWorking distance(mm)
0.5X3.3X-22.5X¢ 61.4-¢ 8.84.9X-33.8X¢ 49.2-¢ 76.5X-45X¢ 40-¢ 5.88.1X-56.3X¢ 37-¢ 5.2150
0.75X4.9X-33.8X¢ 41-¢ 5.97.3X-50.6X¢ 32.8-¢ 4.79.75X-67.5X¢ 26.6-¢ 3.812.2X-84.4X¢ 24.6-¢ 3.5100
1X6.5X-45X¢ 30.7-¢ 4.49.8X-67.5X¢ 24.6-¢ 3.513X-90X¢ 20-¢ 2.916.3X-112.5X¢ 18.5-¢ 2.695
1.5X9.8X-67.5X¢ 20.5-¢ 2.914.6X-101.3X¢ 16.4-¢ 2.319.5X-135X¢ 13.3-¢ 1.922.4X-168.8X¢ 12.3-¢ 1.841
2X13X-90X¢ 15.4-¢ 2.219.5X-135X¢ 12.3-¢ 1.826X-180X¢ 10-¢ 1.432.5X-225X¢ 9.2-¢ 1.326
