Leader Precision Instrument Co., Ltd. >> Binocular Inspection Stereo Microscope for Semiconductors (XTH-2021)

Binocular Inspection Stereo Microscope for Semiconductors (XTH-2021)

Binocular Inspection Stereo Microscope for Semiconductors (XTH-2021)
Price: Negotiable/Piece
Trade Terms: FOB,CIF,EXW
Min Order: 1/Piece
Pay Type: T/T,Western Union
Prod Model: XTH-2021
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Eyepiece: Wf10X/23
Zoom Ratio: 1:6.5
Lens Zoom Range: 1X-6.5X
Total Magnification: 10X-65X
Field Of View: 23mm-3.5mm
Working Distance: 103mm
Interpupillary Distance: 52mm-75mm
Binocular Or Trinocular Tube: Inclined 45/60
Diopter Adjustment: 5 Diopter
Binocular Body Rotation: 360
Type: Biological
Number Of Cylinder: Binoculars
Mobility: Desktop
Shape: Single-lens
Principle: Optics
Magnification: 10-65X

Product Description

Usage:
This stereo microscope is widely used in medical and health, electronics, precision machinery industry and so on, especially suitable to inspect the naked IC, LCD printing paste, PC

Feature:
1) Zoom lens microscope
2) Inclined 45/60 degree observation
3) Erect image
4) Can connect CCD camera

Standard delivery:
Main unit: 1PCS
Eyepiece patch: 2PCS
Anti-dust cover: 1PCS

Optional accessories:
Eyepiece: WF5X, WF15X, WF20X, WF25X, WF30X
Auxiliary lens: 0.5x, 0.75x, 1.5x, 2x

Technical data
Zoom ratio1: 6.5
Lens zoom range1X-6.5X
EyepieceWF10X/23mm
Total magnification10X-65X
Field of view¢ 23mm-¢ 3.5mm
Working distance103mm
Interpupillary distance52mm-75mm
Binocular tubeInclined 45º /60º
Diopter adjustment± 5 diopter
Binocular body rotation360º

EyepieceWF10XWF15XWF20XWF25X
Auxiliary lensMagnificationField of viewMagnificationField of viewMagnificationField of viewMagnificationField of viewWorking distance(mm)
0.5X5X-32.5X¢ 46-¢ 7.47.5X-48.8X¢ 32-¢ 510X-65X¢ 26-¢ 412.5X-81.25X¢ 24-¢ 3.6163
0.75X7.5X- 48.8X¢ 30.7-¢ 4.711.3X-73.1X¢ 21.3-¢ 3.315X-97.5¢ 7.3-¢ 2.718.8X-121.9X¢ 16-¢ 2.5117
1X10X-65X¢ 23-¢ 3.515X-97.5X¢ 16-¢ 2.520X-130X¢ 13-¢ 225X-162.5X¢ 12-¢ 1.8100

1.5X
15X-97.5X¢ 15.3-¢ 2.422.5X-146X¢ 10.7-¢ 1.630X-195X¢ 8.7-¢ 1.337.5X-243.8X¢ 8-¢ 1.245
2X20X-130X¢ 11.5-¢ 1.830X-195X¢ 8-¢ 1.240X-260X¢ 6.5-¢ 150X-325X¢ 6-¢ 0.940
Dongguan Leader Precision Instrument Co., Ltd. is a hi-tech enterprise specializing in R&D, production and sales of optics, machinery and electronic precision measuring and testing instruments, our range includes: Video measuring system, profile projector, coordinate measuring machine, measuring microscope, linear scale and digital readout, video measuring machine, optical comparator, VMM, VMS, vision measuring machine, non-contact 2D video measuring system, Hardness tester, and also stereo microscope, biological microscope, LCD inspection microscope, metallographic microscope etc which are widely used in metrological, measuring, inspecting, testing and reverse engineering fields.

Our continuous excellent products supply sustainable value for our large client word-wide. With powerful strength and good reputation, our products have been exported to more than 30 countries. We are committed to raise the standards of our products and improve the services. We are dedicated to ensure superior products, timely delivery, competitive price and excellent after-sale service

We have a proficient and strong workforce, comprising of technically skilled professionals, who have rich experience in dimension measurement and data analysis in machinery, mould, electronic, aviation, automobile, plastic, gear, PCB circuit board, spring, connector, semiconductor, precision parts and so on.

We guarantee quality and high performance of our products and offer excellent services. Our continuous effort towards producing superior quality products and perfection has helped us to win the trust, confidence and assurance of the customers from all over the globe. Our products have received a great response and recognition in the customers. You can depend on our products for superiority, reliability and durability.
