| Prod Model: |
B5817WS |
| Power Dissipation: |
200 |
| Peake Reverse Voltage: |
20 |
| Manufacturing Technology: |
Discrete Device |
| Material: |
Element Semiconductor |
| Type: |
Intrinsic Semiconductor |
| Package: |
SMD |
| Model: |
B5817ws |
| Batch Number: |
2016 |
| Brand: |
Sy |
Product Description
B5817WS-B5819WS
SCHOTTKY BARRIER DIODE
FEATURE
For use in low voltage,
high frequency inverters Free wheeling,
and polanty protection applications
MECHANICAL DATA
Case: Molded plastic body
Terminals: Plated leads solderable per MIL-STD-750, Method 2026
Polarity: Polarity symbols marked on case
Marking: B5817W:SJ, B5818W:SK, B5819W:SL
SURFACE MOUNT SCHOTTKY BARRIER RECTIFIER RANGE
| SOD-323 (SOD-323 PACKAGING DIODES) |
| |
| | | | | | | | |
| TYPE | Maximum Repetitive | Maximum Average | Maximum Forward | Maximum Reverse | Maximum | Power
Dissipation | Package |
| Peak Reverse | Rectified | Voltage | Current@VRRM | Reverse |
| Voltage | Current | @TA=25ºC | TA=25ºC | Recovery Time |
| VRRM | I(AV) | IF | VF | IR | VR | trr | Pd |
| V | mA | mA | V | μA | V | ns | W |
| 1N4148WS | 100 | 150 | 50 | 1.0 | 0.025 | 20 | 4 | 200 | SOD-323 |
| 1N4448WS | 100 | 250 | 100 | 1.0 | 0.025 | 20 | 4 | 200 |
| 1SS355 | 80 | 100 | 100 | 1.2 | 0.1 | 80 | 4 | 200 |
| 1SS357 | 40 | 100 | 100 | 0.6 | 5 | 40 | 4 | 200 |
| B5817WS | 20 | 1000 | 1000 | 0.45 | 1000 | 20 | -- | 200 |
| B5818WS | 30 | 1000 | 1000 | 0.55 | 1000 | 30 | -- | 200 |
| B5819WS | 40 | 1000 | 1000 | 0.55 | 1000 | 40 | -- | 200 |
| BAT42WS | 30 | -- | 10 | 0.40 | 0.5 | 25 | 5 | 200 |
| BAT43WS | 30 | -- | 15 | 0.45 | 0.5 | 25 | 5 | 200 |
| BAV16WS | 100 | 150 | 50 | 1.0 | 0.025 | 20 | 4 | 200 |
| BAT60B | 10 | -- | 100 | 0.38 | 15 | 5 | -- | 250 |
| BAT54WS | 30 | 100 | 100 | 1.0 | 2 | 25 | 5 | 200 |
| SD101AWS | 60 | -- | 1 | 0.41 | 0.2 | 50 | 1 | 200 |
| SD101BWS | 50 | -- | 1 | 0.40 | 0.2 | 40 | 1 | 200 |
| SD101CWS | 40 | -- | 1 | 0.39 | 0.2 | 30 | 1 | 200 |
| SD103AWS | 40 | -- | 20 | 0.37 | 5.0 | 30 | 10 | 200 |
| SD103BWS | 30 | -- | 20 | 0.37 | 5.0 | 20 | 10 | 200 |
| SD103CWS | 20 | -- | 20 | 0.37 | 5.0 | 10 | 10 | 200 |
