| Prod Model: |
B0540W |
| Power Dissipation: |
410 |
| Peake Reverse Voltage: |
40 |
| Manufacturing Technology: |
Optoelectronic Semiconductor |
| Material: |
Compound Semiconductor |
| Type: |
Intrinsic Semiconductor |
| Package: |
PGA(',Pin Grid Array Package) |
| Model: |
B0540W |
| Batch Number: |
2016 |
| Brand: |
Sy |
Product Description
B0520LW/B0530W/B0540W
SCHOTTKY DIODE
FEATURE
Low forward voltage drop
Guard ring construction for transient protection
High conductance
Also available in lead free version
MECHANICAL DATA
Case: Molded plastic body
Terminals: Plated leads solderable per MIL-STD-750, Method 2026
Polarity: Polarity symbols marked on case Marking: B0520LW:SD, B0530W:SE, B0540W:SF
al;font-size:9.0000pt;" > Also available in lead free version
SURFACE MOUNT SCHOTTKY BARRIER RECTIFIER RANGE
| | | | | | | | |
| TYPE | Maximum Repetitive | Maximum Average | Maximum Forward | Maximum Reverse | Maximum | Power
Dissipation | Package |
| Peak Reverse | Rectified | Voltage | Current@VRRM | Reverse |
| Voltage | Current | @TA=25ºC | TA=25ºC | Recovery Time |
| VRRM | I(AV) | IF | VF | IR | VR | trr | Pd |
| V | mA | mA | V | μA | V | ns | W |
| 1N4148W | 100 | 150 | 50 | 1.0 | 0.025 | 20 | 4 | 400 | SOD-123 |
| 1N4448W | 100 | 250 | 100 | 1.0 | 0.025 | 20 | 4 | 400 |
| B0520LW | 20 | 500 | 500 | 0.43 | 250 | 20 | 4 | 410 |
| B0530W | 30 | 500 | 500 | 0.43 | 130 | 30 | 4 | 410 |
| B0540W | 40 | 500 | 500 | 0.51 | 10 | 20 | 4 | 410 |
| B5817W | 20 | 1000 | 1000 | 0.45 | 1000 | 20 | -- | 250 |
| B5818W | 30 | 1000 | 1000 | 0.55 | 1000 | 30 | -- | 250 |
| B5819W | 40 | 1000 | 1000 | 0.55 | 1000 | 40 | -- | 250 |
| BAT42W | 30 | -- | 10 | 0.40 | 0.5 | 25 | 5 | 200 |
| BAT43W | 30 | -- | 15 | 0.45 | 0.5 | 25 | 5 | 200 |
| BAV16W | 100 | 150 | 50 | 1.0 | 0.025 | 20 | 4 | 400 |
| BAV19W | 100 | 200 | 100 | 1.0 | 0.1 | 100 | 50 | 250 |
| BAV20W | 150 | 200 | 100 | 1.0 | 0.1 | 150 | 50 | 250 |
| BAV21W | 200 | 200 | 100 | 1.0 | 0.1 | 200 | 50 | 250 |
| SD101AW | 60 | -- | 1 | 0.41 | 0.2 | 50 | 1 | 400 |
| SD101BW | 50 | -- | 1 | 0.40 | 0.2 | 40 | 1 | 400 |
| SD101CW | 40 | -- | 1 | 0.39 | 0.2 | 30 | 1 | 400 |
| SD103AW | 40 | -- | 20 | 0.37 | 5.0 | 30 | 10 | 400 |
| SD103BW | 30 | -- | 20 | 0.37 | 5.0 | 20 | 10 | 400 |
| SD103CW | 20 | -- | 20 | 0.37 | 5.0 | 10 | 10 | 400 |
