Automatic Water Level Controller

Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Exported:	More 80 Countries
Price:	Competitive
Installation:	Easy
Technology:	Advanced
Quality:	World-Class

Product Description

automatic water level controller
1. This type flow switch has small structure and wide usage and suit for the external environment
2. Easy to use, safe and reliable, small structure, fast response, long working life, low cost, good corrosion resistance and anti-shock load capability
3. Widely used in shipbuilding, paper, pharmaceutical, printing, plastic auxiliary equipment, petrochemical, food industry, water treatment, electrical, industrial dyes, hydraulic machinery etc.

Main features
1. Can be directly installed on the vessel wall point and It is very convenient to install
2. The switch adopt stainless steel material and isolate with the outside
3. So it has long working life, anti-explosion, anti-corrosion and other characteristics.



Type: CX-FLM-UQK-01
Protection class: DIIBT4
Medium Pressure: 1.0 MPa
Medium temperature (C): Normal: Less than 100C /High-temp: Less than 350C
Net weight: 1.5~2.0Kg
Switch difference(mm): Less than 8
Tuning method: Not adjustable
Installation type: Horizontal installation
Power and contact capacity and working life (option):
AC: 220V/1.5A\110V/2.5A
DC: 24V/2.5A\240V/0.5A
Working life: 5*100^2



Payment term
1. Loading Port: Shanghai China
2. Samples Leading Time: 3-7 working days
3. Delivery Time: Within 7-15 days after payment
4. Payment: T/T, Western Union, Paypal

After-sales service
1. Warranty: The warranty period is 12 months starting from the shipping date
2. Customers will enjoy free repair services for failures found within the warranty due to manufacturing quality
3. For on-site services not arising from manufacturing quality, we shall charge a certain ser After-sales service vice fee at our discretion based on actual charges incurred such as travel exp
4. We provide paid repair services for meter damages not arising from manufacturing quality issues or meter damages not within the scope of warranty.

Installation	Horizontal side mounted ( G1 is exterior , G2 is inbuilt )
Installation screw	G1 is NPT1/2" , G2 is M10 ~ M16
Electric connection	300mm, UL1430 AWG22
Material	SUS304
Application ration	Above 0.65
Working pressure	20 Bar
Working temperature	-10 ~ 80°C
Accuracy	±2mm (in the water)
Repeatability	±1mm (in the water)
Form switch	N.C./N.O
Working voltage	250Vac, 200Vdc
Contact capacity	0.7A/50W/SPST
Float dimension	Dia.17 * 55
