63A with Zero Current Transformer

Name: 63A with Zero Current Transformer
Brand: all-electronics-online.com
SKU: 711099655
Availability: InStock
Rating: 5 (56 reviews)

Price:	US $ 4.1-4.5/Piece
Trade Terms:	FOB,CIF,EXW
Min Order:	5000/Piece
Pay Type:	L/C,T/T,Paypal,Money Gram,Western Union

Contact Supplier

Showroom Product Company Profile

Prod Model:	H-CT004-25D
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Model:	H-CT004-25D
Max Current:	63A
Secondary Current:	20mA
Isolation Voltage:	3000V
Secondary Load:	≤5W
Diameter:	25mm
Coil Turn:	5000:1
Phase:	Single or Three
Color:	Red
Manufacturer:	Jiaxing Haihan Electron Co., Ltd
Application:	Instrument

Product Description

1, Specification notes

1). Outlook face using Flame retardant ABS with black/red color.

2), Output method: Wire with length 150cm.

3), Dimension(Unit: Mm).

4), Mainly using for Ground fault detection or Residual current detection

2, Mainly using for:

1). Clamp-on Current Transformer,

2). Clip on current transformer,

3). Current transformer clamp,

4). Current transformer

3, Quality guarantee!

A, Competive price

B, Perfect service.

If you want to know more information for this model: H-CT004B, Please feel free to contact with us.

Thank you very much for your attention.

Item	Spec	Item	Spec
Frequency	50HZ-60HZ	Coil Ratio	5000: 1
Primary Current	0-120A	Accuracy	0.5Class
Secondary Current	0-20mA	Line insulation	1000V
Setting Pinot	1000mA	Insulation Voltage	≥ 3000VAc
Rate Error	0.2%	Insulation strength	500MΩ /500V/min
Main Circuit current	120A	Coil Resistance	Real tested ± 0.5%
Load Resistance	100Ω	Work Temp	-20º C ~ +80º C

Jiaxing Haihan Electronic Co., Ltd was established in 2011, We are a professional in designing and manufacturing electricity energy meter accessory and hotel supply.

Mainly electricity meter accessory including: Current transformer, stepper motor counter, Manganin shunt, magnetic latching relay, electricity energy meter case, DIN-Rail Watt-hour meter and precision components, Hotel utensil including: Hotel minibar, safe box and wine cooler.

Outstanding employees, advanced technology, superior equipment, and strict management are pivotal to a company's development and to win customers' trust on its products. "Accurate, reliable, and professional" is our belief in producing and servicing.

Since the establishment, It has been absorbing the advanced technology at home and abroad. At the same time we are also learning experience from the whole electronic industry, so we are producing products with precision, stability, reliability leading in Chinese market. With the advanced technology, excellent quality, perfect service, our products are selling through all around the world.

Jiaxing Haihan Electron Co., Ltd provides professional pre-sale, sale, after sale service which has won our customers' trusts and praises from domestics and overseas. We are focusing on the innovation of technology, the quality of management, and the improvement of services in different levels to achieve our development.

We are actively involved in activities of promoting and exchanging. During the long-term development the company will perfect the quality and performance of products, the technology, and establish long-term friendly cooperation relationship with companies from all around the world. We sincerely welcome all customers at home and abroad to visit our company and exchange the technology.
